Features and Advantages
1.Integrated design with small size and light
2.Different sub-models with difference specification
3.Imported safety case,professional and portable
4.Built in energy-storage capacitor without HV leak and safe operation
5.HV directly connect with the faulty cable, easy wiring and safe operation
6.Built-in high power quick charging and short discharge period
7.Multiple safety protection support Zero position start and release HV power energy after power off
8.Multiple working methods of single,period and DC
9.Step adjustable voltage with LED indication
Parameter
| Output surge voltage | 0～32KV, Step variable |
| Max. power energy | 2000J |
| Energy-storage capacitor | 4μF |
| Power | AC 220V.50Hz |
| Volume | 400mm×460mm×300mm |
| Weight | 25 kg |
| Operating Temperature | -10℃－40℃ |
| Humidity | 5-90％RH |
| Elevation | <4500m |
