Features and Advantages
1. The cross-voltage measurement range is 0.22kV~220kV.
2. The maximum transmission line of sight of the transmitter and receiver is approximately 100 meters.
3. The distance between two GPS hosts in the remote nuclear phase is 0.3 km to 800 km.
4. The voice prompt measurement results and operation steps of the live voice.
5. 3.2-inch color screen simultaneously displays 2 line phase difference, frequency, vector and the same-phase results, showing the number of GPS satellites, GPS timing status and time and other information.
6.automatic operation for 1 hour without operation.
7.Both the transmitter and the receiving host have a built-in rechargeable lithium battery and a 5V charger.
8. The transmitter and the receiving host transmission distance is more than 130 meters, the maximum distance between the two transmitters is about 260 meters.
Parameter
| Accuracy | When phase sequence is same: the error≤ 5 °. | |
| The frequency accuracy | ±0.1HZ. | |
| Measuring voltage range | 6KV – 35KV. | |
| High pressure when measuring the leakage current | < 10 uA | |
| Working environment | temperature – 40 ℃ —— + 55 ℃; | |
| humidity | ≤95% RH | |
| weight | about 5 KG | |
| Instrument package size | 71 cm * 26 cm * 11 cm | |
