Features and Advantages
1.The 32-bit embedded microprocessor is used as the main control core to embed the mini operating system.
2.0-400ma automatic detection, high precision, fast measurement speed, stable and reliable.
3.The motherboard adopts high-quality SMT components with high integration, simple operation and long service life
4.Contains 4 calculation formulas, and the measurement results are automatically converted to the required units and can be converted to each other.
5.Color touch screen, full numeric keyboard, more concise operation, convenient and quick data calculation.
6.With graph curve analysis to help analyze water content trend.
7.Switching between Chinese and English at any time.
Parameter
| Titration method | Coulometric titration（Coulomb analysis） |
| Display | Color LCD touch screen |
| Electrolytic current control | 0～400mA automatic control |
| Measurement scope | 1ug～200mg |
| Sensitive valve | 0.1µg H2O |
| Accuracy | 10µg～1000µg±3µg More than 1mg but not greater than 0.3% |
| Printer | Miniature thermal printer |
| Power supply | 220V±10%、50Hz |
| Power | ＜ 40W |
| Ambient temperature | 5～40℃ |
| Ambient humidity | ≤ 85% |
| External dimension | 380×310×180 |
| Weight | About 6kg |
