Features and Advantages
1. Hall effect sensor AC/DC current 40A/400A measurement (UT213C only)
2. Automatic range, more rapid and effective measurement
3. The maximum display is 3999 words of reading, and the sampling rate is 3 times per second
4. True RMS, effective expression of abnormal AC signal (only UT213B/C)
5. With NCV non-contact AC power test function
6. With frequency and duty cycle measurement function
7. Flashlight function, suitable for night or dark work
8. With K-type point temperature probe temperature measurement function (only UT213B/C)
9. LCD backlight function can effectively read in dark environment
10. Through the impact strength test, it can withstand the impact of one meter on the ground
Parameter
| Basic function | Range | Accuracy | ||
| Model | UT213A | UT213B | UT213C | |
| AC current(A) | 4A/40A/400A | ±（1.8%+9） | ±（1.8%+9） | |
| 40A/400A | ±（2.5%+5） | |||
| DC current(A) | 40A/400A | ±（2.0%+3） | ||
| AC voltage (V) | 4V/40V/400V/600V | ±（1.2%+5） | ±（1.2%+5） | ±（1.2%+5） |
| DC voltage (V) | 400mV/4V/40V/400V/600V | ±（0.8%+1） | ±（0.8%+1） | ±（0.8%+1） |
| Resistance (Ω) | 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ | ±（1.0%+2） | ±（1.0%+2） | ±（1.0%+2） |
| Capacitance (F) | 50nF/500nF/5uF/50uF/100uF | ±（4.0%+5） | ||
| 40nF/400nF/4uF/40uF/400uF/4mF/40mF | ±（4.0%+5） | ±（4.0%+5） | ||
| Frequency (Hz) | 10Hz~1MHz | ±（0.1%+4） | ±（0.1%+4） | ±（0.1%+4） |
| Maximum value display | 3999 | 3999 | 3999 | |
| Opening size | 30mm | 30mm | 30mm | |
| Diode test | 约1.5V | 约3V | 约3V | |
| Fuselage size | 220x75x40mm | |||
| Fuselage weight | 280g（UT213A/B） 231.7g（UT213C） | |||
