Features and Advantages
1.It can be externally connected to the pressure chamber to form positive/negative pressure, so as to realize the detection of high-viscosity samples and sample degassing.
2.Built-in data analysis system can display the real data of particle size of each channel and automatically determine the sample grade.
3.The pipeline is made of 316L and PTFE materials to meet the detection of various organic solvents and oils.
4.With volume flushing and duration flushing mode, it is convenient for users to use and maintain the equipment.
5.Built-in ISO4406, NAS1638, SAE4059 (integral and differential), GJB420A, GJB420B Г OCT17216, GB/T14039 and other particle pollution level standards.
6.Built-in calibration function, which can be calibrated according to GB/T21540, ISO4402, GB/T18854 and other standards.
7.Built-in data analysis system can automatically determine the sample grade according to the standard, with automatic data processing and printing functions.
8.Built-in micro-water sensor and temperature sensor.
9.With preset, input, modification and storage functions, easy and fast operation.
10.Large storage, which can be stored in the internal or external storage device of the instrument.
11.Embedded design, high-strength shell, easy to carry.
Parameter
| Light source | semiconductor laser |
| Offline detection speed | 5~60mL/min |
| Viscosity of sample tested offline | ≤ 100cSt (pressure chamber can be selected as optional accessory when the viscosity is high) |
| Online detection pressure | 0.1~0.6Mpa (the maximum pressure can reach 42Mpa when select the optional pressure reducing device) |
| Particle size range | 0.8~600μm |
| Sensitivity | 0.8μM or 4μm（c) |
| Limit coincidence error | 40000 grains/ml |
| Counting volume | 1~999ml |
| Counting accuracy | error less than ± 10% |
| Test interval | 1 second ~ 24 hours |
| Test sample temperature | 0~80 ℃ |
| Reference value of water activity | 0~1aw (± 0.05aw) |
| Water content | 0~360ppm (± 10%) |
| Protection grade | IP67 |
| Interface | USB interface, battery charging interface |
| Data storage | provide 1000 sets of data storage space and support USB flash disk storage |
| Working temperature | -20~60 ℃ |
| Power supply | DC12V |
| Screen size | 10.2 inches |
| Battery capacity | 8000mAh |
| Size | 365*295*170mm |
| Net Weight | 5.5kg |
