Features and Advantages
1. With a microprocessor, automatically fulfill the withstand voltage test for oil circulation with a range of 0~100KV(including boosting, maintaining, mixing, standing, calculation, printing and other operations).
2. Display by large-screen LCD and prompt by English menu.
3. Simple operation. The machine will automatically complete the withstand voltage test on one cup of sample oil after simple setting by the operator. Breakdown voltage value of 1 to 6 times and recurrent times will be automatically saved. After the test, the thermal printer will print each breakdown voltage value and average value.
4. Power-down preservation. It can save 100 tested results and displaying current ambient temperature and humidity.
5. Adopt a single-chip microcomputer to boost the voltage at an even speed. The voltage is accurate at 50Hzor60Hz, ensuring thewhole process easy forcontrol.
6. Equipped with over-voltage, over-current and limit protections to ensure the safety of operators.
7. With the function of displaying the measured temperature and system clock.
Parameter
| Technicalindicators | |
| Booster capacity | 1.5kVA |
| Booster speed | 0.5～5 kV/S (adjustable) |
| Poor miss: 0.2kV/s | |
| Output voltage | 0~100kV |
| Voltage accuracy | ±3％ |
| Power distortion factor | ＜3% |
| Display mode | Large screen LCD character display |
| The electrode spacing | Standard 2.5mm |
| Test times | 1～9 time(s) (optional) |
| Resting time | 15min (adjustable) |
| Interval rest time | 5 min (adjustable) |
| Stirring time | 15s (adjustable) |
| Overall dimensions | 465mm*385mm*425mm |
