Features and Advantages
1.output 0 ~ 7000A current
2.The operation time of test equipment can be synchronized
3.Automatic identification of normally open and normally closed contacts
4.Can be several serial check at the same time, improve work efficiency
5.Directly display the test values of primary current and secondary current for the convenience of test observation and recording.
6.Six and a half display, the national initiative six and a half display, display accuracy is higher, more accurate experimental results
7.Large LCD display, display data more intuitive, faster reading
8.The meter display locking function, especially for the transformer can be more accurate and faster than the test
9.Use beautiful and generous PVC panel, make the panel more resistant to dirt and wear
10.The measurement accuracy is 0.1 grade higher
11.large power, small size, with a strong load capacity
12.Small size, light weight, volume of similar products only 30% ~ 70%, very convenient to carry.
Parameter
| Input | AC 50Hz, 380V |
| Output | single phase 0-7000A ac current; The current can be adjusted smoothly, smoothly and continuously, with the accuracy higher than 0.2. |
| Output current mode | true RMS value is continuously adjustable |
| Output waveform | standard sine wave |
| Output opening voltage | 5V |
| Current accuracy | each current can be adjusted smoothly, steadily and continuously, with the accuracy higher than 0.5 |
| Current stability | 0.1% |
| Current waveform distortion | THD 1% |
| Protection Settings | overcurrent, overvoltage |
| Measuring time range | 0.0001s — -9999.9999s, accuracy: 0.0001s |
| The current action time of the tested element can be measured and the locked action time can be recorded synchronously. Automatic identification of normally open and normally closed contacts. | |
