Features and Advantages
1. No need to dismantle the vacuum switch in measurement;
2. Two types of magnetic coil for different measuring method;
3. Can test many types of vacuum switch;
4. Menu on LCD screen, easy to operate;
5. Data storage, Viewed and Printed functions;
6. RS-232 port to Computer;
7. Light weight, Portable.
Parameter
| Measuring range | 10-5～10-1 Pa | |
| measurement accuracy | 10-5～10-4 Pa，10% |
| 10-4～10-3 Pa，10% | |
| 10-3～10-2 Pa，10% | |
| 10-2～10-1 Pa，10% |
| Magnetic field voltage | 1700V | |
| Use environment | -20℃~40℃ | |
| Host weight | 24kg | |
| Dimensions | 410×320×370mm3 | |
| Sampler | Magnetron coil | |
