Features and Advantages
1. Color Touch Screen: 800*480 high resolution color 7′′ touch screen, user interactive interface, high-speed thermal printer.
2. Large-range current output:Adopt the latest power supply technology, long time continuously output big current, large-range current output. Can set 1 to 3 different current range for testing, and automatically calculate average value.
3. Digital displaying data information:Resistance, voltage, current, electrical resistivity，resistance values at converted standard temperatures.
4. Auto-alarm of over limit:Set resistance up-limit value of pass / over limit / invalid, automatically generate testing status.
5. Long-time testing: Can set test time from 0-9999s and support long-time working. Inside cold-wind heat dissipation, switch power automatically protection.
6. High-precision measurement: Use Operational amplifiers from precision instruments and High precision quadruple integral A/D converter.
7.Latest System IC:Use High performance 32-bit latest ARM chips, System automatically switch magnification times based on signal, ensure testing precision.
8.Inside Calendar & Clock:provide accurate time of testing and printing.
9. DC constant current source function:Can output current from 0 to infinite value, built-in current step-by-step up-flow test, equal to another powerful DC constant current source for test.
10. Large-volume testing record storage:Build-in large capacity storage for look up, also have data protection function while power shut down suddenly.
11. Removable USB flash drive data access:Expert excel file data record.
12. Standard Modbus-RTU: Build-in RS232 port (customized convert to RS485), communication protocol Modbus-RTU.
13. Computer control and upload test data: Build-in RS232 port for the data control, upload, generate word/excel file.
14. Blue tooth control and upload data:Standard configuration blue tooth function, build-in android BT APP for data control / upload / generate word file.
15. Convenient cable operating:Cable control mode (customized), set cable control switch to regulate open / touch, test / interruption, light-alarm for resistance output over limit.
16. Quick and convenient wireless remote controller:it is customized, with one button operation of testing and interruption, customized controller can show the test progress.
17. Temperature offset automatically calculate resistance:Can preset temperature, automatically calculate resistance in standard temperature. Also use temperature sensor (customized) to measure.
18. Background color change: Set background color to blue and graphic black, brightness, standby brightness and time.
19. Build-in training material:Document shows the cable connecting method for onsite guidance.
20. Chinese input test information:Key in test spot, equipment, person, remark etc, convenient to remark and store test data and printing.
21. Big current cable quick connection: Use latest big current cable port, insert and turn lock up.
22. Multiple-phase selection:Normal is single-phase, customized to be two-phase test and three-phase test simultaneously.
Parameter
| Selection | 100A | 200A | 300A | 400A | 500A | 600A | 10-5000A |
| Measurement range | 20A 50A 100A customized | 20A 50A 100A 150A 200A customized | 20A 50A 100A 150A 200A 300A customized | 20A 50A 100A 150A 200A 300A 400A customized | 20A 50A 100A 150A 200A 300A 400A 500A customized | 20A 50A 100A 150A 200A 300A 400A 500A 600A customized | Current customized 1, two-phase 2, three-phase |
| Test range | 0~19999uΩ expandable | ||||||
| Test precision | 0.5%rdg±10dgt | ||||||
| Resolution | 0.01uΩ | ||||||
| Working power | AC 220V±10% 50Hz±2% | ||||||
| Length(mm) | 450 | 450 | |||||
| Width(mm) | 250 | 250 | |||||
| Height(mm) | 220 | 280 | |||||
| Weight(Kg) | 9.9 | 12.9 | |||||
| Environment temperature | －25ºC ~50ºC | ||||||
| RH | £90%RH | ||||||
