Features and Advantages
1、The instrument has large output current and light weight.
2、The open circuit voltage output of the instrument is 28V. The transition resistance of 10 Ω can be tested under the current of 1A gear, and 0.5A and 0.3A gears are set to facilitate the test Large transition resistance.
3、It has perfect protection circuit and strong reliability.
4、The vertical LCD case is 7.5 inches, which is convenient for field operation.
5、With USB flash disk storage function, more data waveforms can be stored.
Parameter
| Output current | 1.0A, 0.5A, 0.3A, three gears optional |
| Resistance range | 1.0A gear 0.1 ~ 10 Ω; 0.5A gear 5 ~ 20 Ω; 0.3A gear 10 ~ 40 Ω |
| Resistance measurement accuracy | ± (reading) × 5% + 5 words), resolution: 0.01 Ω |
| Transition time measurement range | 1～250mS |
| Transition time measurement accuracy | ± 1ms, resolution: 0.1ms |
| Sampling frequency | 10K |
| Storage mode | USB flash disk storage, local storage |
| Working temperature | -20℃～+50℃ |
| Environmental humidity | ≤ 90% RH, no condensation |
| Working power supply | AC220V±10%，50Hz±10% |
