Dry type test transformers and inflatable test transformers have their own advantages and disadvantages, and the selection should be based on specific application scenarios and requirements:
① Advantages
a. High safety: using epoxy resin vacuum casting and CD magnetic core technology, oil-free design to avoid fire and explosion risks, especially suitable for places with strict fire prevention requirements.
b. Environmentally friendly and maintenance free: No need for insulation oil, no risk of oil leakage, low operation and maintenance requirements, and low long-term use costs.
c. Stable performance: High insulation strength, strong moisture resistance, suitable for insulation performance testing of electrical equipment in complex environments.
2. Advantages and disadvantages of inflatable test transformers
① Advantages
a. Lightweight and portable: Equipped with SF6 gas insulation, the volume and weight are significantly reduced, making it easy to transport and frequently move on site.
b. High insulation performance: SF6 gas has excellent electrical insulation and arc extinguishing capabilities, suitable for high-precision testing needs, such as factory testing or scientific research experiments of power equipment.
c. Environmental Protection and Safety: Oil free design avoids oil pollution, and SF6 gas is non flammable and non explosive, suitable for flammable and explosive environments or places with high safety requirements.
② Insufficient
a. High cost: The SF6 gas filling process is complex, and the equipment price and maintenance cost are relatively high.
b. High environmental sensitivity: High requirements for temperature, humidity, and other conditions of the usage environment, and SF6 gas leakage may cause pollution to the environment.
c. Difficulty in maintenance: If internal gas escapes, it needs to be returned to the factory for processing, and the maintenance process is complex and time-consuming.
3. Choose Suggestions
① The scenario where dry-type test transformers are preferred:
a. Indoor environments or places with high requirements for fire and explosion prevention.
b. Projects that require long-term stable operation and low maintenance costs.
c. Scenarios with strict requirements for environmental performance.
② Priority should be given to the scenario of using inflatable test transformers:
a. Scenarios that require frequent movement or on-site testing.
b. Places with strict restrictions on equipment weight and volume.
c. In situations where high-precision testing or high security requirements are needed.
