BY2671 Megohmmeter
Description



Product Introduction

BY2671 Megohmmeter consists of medium and large scale integrated circuit with high output power and high short-circuit current value features. The output voltage is up to four grades. The built-in battery served as power supply become high DC voltage by DC/DC transformation, which goes from E pole to L pole via the object being tested. By this way, it produces a current from pole E to pole L, which converted by I/V and computed by the divider. The value of insulation resistance will display on the LCD finally.

Alternative Name

Digital ground resistance tester, ground resistance tester

Product Features

1.High output power, strong load ability, and strong anti-interference ability.
The shell body is made of aldural/high-strength aluminum alloy, equipped with potential protection ring and fourth-order active low pass filter, it can play an effective role in shielding external power frequency and strong electromagnetic field. For the measurement of capacitive specimen, since the short-circuit current is greater than 1.6mA, it’s easy to rise the test voltage to the rating of output voltage. For the measurement of low resistance, it will not affect the test by using scaling method.
2. The meter is battery powered and the measure range is converted automatically. The easy-to-read panel and LCD display make measurement very convenient and fast.
3. The output short-circuit current of the meter can be measured immediately without estimation.

Product Parameters

1. Operating Conditions
Temperature, 0 ℃ ~ +45 ℃
Relative humidity ≤ 85%
2. Measuring range and constant current value (virtual value)
Resistance, 0 ~ 2Ω (10mA), 2 ~ 20Ω (10mA), 20 ~ 200Ω (1mA)
Voltage, AC 0 ~ 20V
3. Measurement accuracy and resolution
Accuracy,0 ~ 0.2Ω ≤ ± 3% ± 1d
0.2Ω ~ 200Ω ≤ ± 1.5% ± 1d
1 ~ 20V ≤ ± 3% ± 1d
Resolution,0.001Ω, 0.01Ω, 0.1Ω, 0.01V
4. Measurement errors caused by auxiliary grounding resistance and ground voltage
Auxiliary grounding resistance RC (between C1 and C2)
0 ~ 2Ω, 2 ~ 20Ω ≤ 1KΩ
v20 ~ 200Ω ≤ 2KΩ
RP (between P1 and P2) < 40KΩ error ≤ ± 5%
Ground voltage (frequency virtual value) ≤ 5V error ≤ ± 5%
5. Power supply and power dissipation
Maximum power dissipation≤ 2W
DC 8 × 1.5V (AA, R6) Battery
AC 220V/50Hz
6. Dimensions and weight
